LAP JOINT STUB ENDS

A Lap Joint Stub End is a short piece of pipe or fitting welded directly to the end of a pipeline, featuring a flanged collar face on one end and a straight welding spigot on the other. It is used in tandem with a loose backing flange (such as an EN 1092-1 Type 02 or ASME lap joint flange) to create a movable, rotating flange connection.

Key Features

• 360° Rotational Alignment: Allows the backing flange to rotate freely during assembly, eliminating bolt-hole alignment issues.
• Cost Optimization: Only the stub end contacts the process fluid, allowing expensive stainless steel or alloy stub ends to be paired with economical carbon steel backing flanges.
• Easy Maintenance: Simplifies joint disassembly and gasket replacement in systems requiring frequent cleaning.

Applications

• Corrosive Chemical Lines: Stainless steel and alloy piping systems handling aggressive media.
• Pulp & Paper Processing: Slurry, chemical recovery, and bleaching lines.
• Water Treatment Plants: Large-diameter low-pressure utility lines and filter manifolds.

Why Choose Hebei Haiyuan Pipe Fitting Co., Ltd.?

When sourcing vital pipeline components, partnering with Hebei Haiyuan Pipe Fitting Co., Ltd. guarantees industrial excellence, reliability, and value:

Direct-from-Factory Advantage: Enjoy competitive pricing without middleman markups, backed by dependable global logistics and prompt customer support.

Advanced Manufacturing & Forging Expertise: We utilize state-of-the-art hot forging and precision CNC machining technology to optimize metal grain structures and ensure absolute dimensional accuracy.

Rigorous Quality Assurance: Every batch undergoes strict testing, including chemical composition analysis, mechanical property verification, and non-destructive examination (UT/MT) before shipment.

International Standards Compliance: Our production strictly adheres to European specifications (EN 1092-1), ensuring seamless compatibility with global piping networks.

Comprehensive Inventory & Customization: We maintain extensive stock readiness across various sizes (DN) and pressure ratings (PN), while also offering custom engineering for unique project blueprints.

Technical Parameters

FAQ

Q:May I have free sample before ordering?
A:Yes,we are pleasured to send you free samples for quality test,but freight cost would be afforded by your side.

Q:What about production time?
A:Sample order:4 - 7 days if out of stock,or deliver at once
Massive order:15 - 45 days against deposit,depending on the quantities.

Q:Do you have any MOQ limit for the products order?
A:Low MOQ,1pcs for sample checking is available.

Q:Do your company have the export license?
A:Yes,we have Sovereignty for exporting and importing.

Q:Which trade terms can I choose?
A:CRF,FOB,CIF,and negotiable accordingly

Q:How about payment term your company accept?
A:For small testing orders,we accept-T/T.
For massive order,we accept T/T and L/C.
